IP Rating Explained: Choosing the Right Protection for LED Lighting

Table of Contents

    IP rating is a key factor when choosing LED lighting for commercial, industrial, or outdoor use. It impacts safety, durability, compliance, and the lighting's lifespan.

    For lighting specifiers and businesses, choosing the correct IP rating helps prevent premature failures, reduce maintenance costs, avoid warranty issues, and ensure compliance with regulatory and project standards.

    Specifiers should verify compliance through a structured process: request manufacturer documentation, including IP test reports and declarations of conformity, and refer to relevant standards, such as IEC 60529. This guide explains IP ratings clearly, shows how to use an IP rating chart, and provides practical, real-world guidance for specifying LED lighting with confidence.

    What Does an IP Rating Mean?

    An IP rating (Ingress Protection rating) is an international standard set by IEC 60529. It shows how well an electrical enclosure protects against:

    • Solid objects such as dust and debris
    • Liquids such as water splashes, jets, or immersion

    Each IP code consists of two digits:

    • First digit: protection against solids
    • Second digit: protection against liquids

    For LED lighting, these ratings indicate whether a fixture is suitable for dry indoor spaces, damp areas, or outdoor locations exposed to the elements.

    Understanding the IP Rating Chart

    An IP rating chart clearly explains the different levels of protection.

    First Digit – Solid Object Protection

    First Digit Level of Protection
    0 No protection
    2 Protection from fingers or large objects
    4 Protection from small tools and wires
    6 Dust-tight (complete protection)

    The chart offers a concise overview of solid object protection levels, serving as a clear reference for specifiers evaluating LED lighting requirements.

    0 – No protection
    2 – Protection from fingers or large objects
    4 – Protection from small tools and wires
    6 – Dust-tight (complete protection)

    Second Digit – Liquid Protection

    Second Digit Level of Protection
    0 No protection
    1 Protection from vertically falling water drops
    2 Protection from water drops at up to 15° angle
    3 Protection from water spray at up to 60° angle
    4 Protection from splashing water from any direction
    5 Protection from water jets
    6 Protection from powerful water jets
    7 Protection from temporary immersion in water
    8 Protection from continuous immersion in water

    This complete sequence provides a reference for evaluating the required level of liquid ingress protection for specific LED lighting applications.

    0 – No protection
    4 – Protection from splashing water
    5 – Protection from water jets
    7 – Protection from temporary immersion

    Reading the chart correctly helps specifiers choose LED lighting that matches real environmental risks, not just the location. The following comparison table illustrates how IEC 60529 distinguishes between different application environments and specifies the corresponding IP requirements:

    Environment Typical Exposure Minimum IP Rating Justification
    Car parks Rain and dust IP65 Protects against complete dust ingress and water jets
    Food processing areas Frequent moisture, washdowns IP66 Ensures total dust-tightness and resistance to powerful water jets
    Warehouses Airborne dust, occasional water IP64 Prevents dust entry and protects from splashing water

    This table provides a clear reference for matching IP ratings to specific environmental requirements, thereby ensuring compliance with the prescribed operational standards in each context.

    Common IP Ratings Used in LED Lighting

    IP20 / IP33 – Dry Indoor Areas

    Suitable for offices, retail displays, and controlled environments with minimal moisture or dust.

    IP44 Rating – Splash-Proof Protection

    IP44 what it means
    The IP44 rating protects against solid objects over 1mm and water splashes from any direction.
    Common applications include:
    • Bathrooms (outside direct water zones)
    • Kitchens
    • Covered outdoor areas
    • Commercial interiors with occasional moisture
    IP44 offers a good balance between protection and flexibility at a reasonable cost.

    IP67 Waterproof – High-Level Protection

    IP67 waterproof what it means

    IP67 waterproof LED lighting is fully dust-tight and protected against temporary immersion.
    Typical uses include:
    • Outdoor and garden lighting
    • Ground and deck installations
    • Architectural and façade lighting
    • Industrial and commercial exteriors
    This rating is best for places where weather exposure or water contact cannot be avoided.

    IP44 vs IP67: Which IP Rating Do You Need?

    The right choice depends on actual exposure, not just whether the lighting is indoor or outdoor.
    Choose IP44 when:
    • Water exposure is occasional.
    • Fixtures are sheltered
    • No direct rainfall or pooling occurs.
    Choose IP67 when:
    • Lighting is fully exposed to the weather.
    • Fixtures may be submerged temporarily.
    • Dust or dirt ingress is likely.
    Choosing an IP rating higher than the minimum is often a smart way to reduce risk in commercial projects.

    Specifying IP Ratings for Borderline & Mixed-Use Environments

    Many real-world installations fall into grey areas, such as:
    • Covered walkways and canopies
    • Semi-open retail frontages
    • Loading bays
    • Indoor spaces are subject to washdowns.
    In these cases, specifiers should assess real exposure conditions, including:
    • Wind-driven rain
    • Cleaning methods
    • Airborne dust or grease
    • Seasonal weather changes
    Best practice:
    If exposure conditions are uncertain, specifiers should select an IP rating one level above the minimum. For instance, opting for IP65 instead of IP44 increases upfront costs by only 10–15%, yet research shows this can lower maintenance expenses by up to 20% and reduce failure rates by as much as 30% over five years. These long-term savings typically outweigh the initial investment, providing greater value and reliability.

    Choosing the Right IP Rating by Environment

    Indoor Commercial Spaces

    Most retail and office spaces require IP20 to IP44 ratings, depending on how often and thoroughly they are cleaned.

    Bathrooms, Kitchens & Wet Zones

    IP44 usually works well outside splash zones, but higher ratings may be needed near water sources.

    Outdoor, Garden & Façade Lighting

    For fully exposed installations, use IP65 or higher. IP67 is recommended for ground-level lights.

    Industrial & High-Exposure Areas

    Dust, frequent cleaning, and harsh environments require higher IP ratings for long-lasting, safe lighting.

    IP Rating Compliance & Verification

    What Documentation Should You Request?

    An IP rating should always be supported by documentation. Specifiers should request:
    • Manufacturer’s IP test reports
    • Declaration of Conformity referencing IEC 60529
    • Third-party laboratory certifications (where available)
    • Make sure datasheets clearly state the IP rating. Specifiers should request manufacturer IP test reports, a Declaration of Conformity referencing IEC 60529, and third-party lab certifications, if available. Avoid vague terms like "weather resistant" or "water resistant" unless a specific IP code is given, and always request the exact IP rating. This practice clarifies the product’s protection level and facilitates regulatory compliance.

    Installation Practices and IP Rating Integrity

    Can Installation Affect an IP Rating?

    Yes. Incorrect installation can compromise even the highest-rated fixtures.
    Common issues include:
    • Damaged or missing seals
    • Incorrect cable glands
    • Over- or under-tightened fixings
    • Unauthorised drilling or modification
    Best practice:
    • Use IP-rated connectors and glands.
    • Follow the manufacturer's torque guidance.
    • Avoid altering housings
    • Ensure seals remain intact.
    An IP rating is valid only if the product is installed as intended and rigorous compliance checks are performed. Essential verification steps include:

    - Confirming that all seals are intact;
    - Selecting and installing the correct cable glands;
    - Adhering precisely to the manufacturer's torque specifications.

    By systematically documenting and verifying each compliance check, specifiers can ensure the IP rating is maintained in accordance with relevant standards, thereby maintaining effective protection for LED lighting fixtures on site.

    Maintenance, Cleaning & Long-Term Performance

    Maintenance has a direct impact on the longevity of IP-rated LED lighting.
    Risks include:
    • Pressure washing fixtures not designed for it.
    • Chemical cleaners degrade seals.
    • Dirt is preventing proper drainage.
    • Repeated opening without resealing
    Best practice:
    • Match cleaning methods to the IP rating.
    • Inspect seals during routine maintenance.
    • Replace damaged gaskets promptly.
    • Minimise unnecessary access to enclosures
    Higher IP ratings make lighting more durable in tough maintenance conditions.

    Why IP Ratings Matter for LED Performance & Longevity

    In summary, selecting the incorrect IP rating frequently results in premature LED fixture failure due to moisture ingress, which can cause corrosion, electrical faults, diminished light output, and early malfunction, often leading to voided warranties. To prevent these problems, it is essential for specifiers to: (1) select an IP rating appropriate for the environmental conditions; (2) follow the manufacturer's installation guidelines precisely; and (3) use materials and finishes suitable for the intended setting. Adhering to these actionable steps reduces the risk of warranty issues and helps ensure long-term performance. Specifiers are encouraged to take a proactive approach by thoroughly assessing exposure risks and verifying compliance at every stage of the project. This commitment to proper specification and installation is fundamental to achieving reliable, compliant, and durable LED lighting solutions.
    • Selecting the appropriate IP rating improves the lifespan of LED lighting fixtures by providing adequate protection against environmental factors that can shorten operational life.
    • Reduces maintenance costs
    • Enhances safety
    • Supports regulatory compliance

    How Super Led Lights Approach IP-Rated LED Lighting

    At Super Led Lights, we match IP ratings to real-world uses, not just technical specs. We focus on:
    • Application-led product selection
    • Proven protection standards
    • Long-term commercial reliability
    • Reducing risk for specifiers and installers

    FAQs About IP Ratings

    What does an IP rating indicate?

    It shows how well a product is protected against dust and water ingress.

    Is IP44 suitable outdoors?

    IP44 is suitable only in sheltered outdoor locations. Fully exposed areas require higher IP ratings.

    Does waterproof mean submersible?

    No. Only ratings such as IP67 allow protection against temporary immersion in water.

    Can incorrect installation affect IP performance?

    Yes. Poor installation can compromise seals, reduce protection, and potentially void warranties.

    Does maintenance impact IP-rated lighting?

    Yes. Cleaning methods, environmental buildup, and seal condition directly affect long-term performance.
